ZN39-40.5 Indoor High Voltage Vacuum Circuit Breaker
2. Operating Mechanism: Modular mechanism
3. Installation: floor withdrawable type
4. Suitable for cabinet: suitable for JIN1-35, GBC-35 switchgear.
5. Products follow standards:GB/T1984-2014、GB/T11022-2011.
6. Product advantages: E2-C2-M2 performance, easy and convenient maintenance, high conductivity, and stable performance.
Send Inquiry
Product Introduction
ZN39-40.5 vacuum circuit breaker is a three-phase AC 50Hz, rated voltage 40.5kV indoor high-voltage device. It is matched with JIN1-35 and GBC-35 switchgear, and can be used for accepting, controlling and protecting electric energy in industrial and mining enterprises, power plants and substations.
The circuit breaker adopts air insulation method to meet the insulation requirements of normal operation conditions, with reasonable overall layout, simple structure and convenient installation and adjustment.
The operating mechanism adopts electromagnetic mechanism CD10-II or spring mechanism CT19N, which can be operated by AC or DC or manually.
The circuit breaker has a simple and reliable mechanical interlocking interface, which is convenient for realizing the "five-proof" requirements of the switchgear.
Product Specifications
Specification Sheet
|
No. |
Name |
Unit |
Data |
|
1 |
Rated Voltage |
kV |
40.5 |
|
2 |
Rated Frequency |
Hz |
50 |
|
3 |
Rated Current |
A |
630/1250/1600/2000/2500 |
|
4 |
Rated Power Frequency Withstand Voltage |
kV |
95(Common value) /95(Across the isolating Distance) |
|
5 |
Rated Lightning Impulse Withstand Voltage |
kV |
185(Common value) /185(Across the isolating Distance) |
|
6 |
Rated Short-Circuit Breaking Current |
kA |
25/31.5/40 |
|
7 |
Rated Short-Circuit Making Current (Peak) |
kA |
63/80/100 |
|
8 |
Rated Withstand Current (Peak) |
kA |
63/80/100 |
|
9 |
Rated Duration of Short-Circuit |
s |
4 |
|
10 |
Operating Cycles at Rated Short-Circuit Breaking Current |
Times |
E2 |
|
11 |
Mechanical Endurance |
Times |
10000 |
|
12 |
Standard Operating Sequence |
- |
O-0.3s-CO-180s-CO |
|
13 |
Allowable Wear Thickness of Contact |
mm |
≤3 |
Mechanical Characteristics
|
No. |
Name |
Unit |
Data |
|
1 |
Clearance between Moved and Fixed Contact |
mm |
22±2 |
|
2 |
Contact Overtravel |
mm |
6±1 |
|
3 |
Average Closing Speed |
m/s |
0.6±0.2 |
|
4 |
Average Opening Speed (Average Speed of First Opening at 6mm) |
m/s |
1.4±0.3 |
|
5 |
Rated ContactPressure |
N |
3100±200N(25kA/31.5kA) |
|
6 |
Closing Time |
ms |
30～120 |
|
7 |
Opening Time |
ms |
20～75 |
|
8 |
Contact Bouncing Duration at Closing Operation |
ms |
≤3 |
|
9 |
No-Simultaneity of Closing/Opening Operations of 3-Phase |
ms |
≤2 |
Product Advantages
ZN39-40.5 vacuum circuit breaker has many advantages:
1. Performance of circuit breaker: E2-C2-M2
2. Structural features: the circuit breaker adopts air insulation to meet the insulation requirements of normal operating conditions, reasonable overall layout, simple structure, easy to install and adjust.
3. Mechanism and interlocking: The operating mechanism adopts spring mechanism CT19N, which can be operated by AC or DC and manually. The circuit breaker has a simple and reliable mechanical interlocking interface, which is convenient to meet the "Five-prevention" requirements of the switchgear.
4.Wide range of use: adapting to the harsh environment, the product is able to withstand a low temperature of -25℃. Meet the requirements for use at an altitude of 2000 meters.
Product Applications
VTZ-12(K59) vacuum circuit breaker has many applications:
Power plants
Industrial fields (chemical industry, steel, petroleum, coal, etc.)
Power grid systems
Power infrastructures
Product Outline Drawing
Secondary Wiring Diagram
Special Contact
Our K-59 circuit breaker is compatible with the most common contacts in the Central Asia region, supporting rated currents of 630A, 800A, 1000A, 1250A, 1600A, and 2000A.
Reliable Vacuum Circuit Breakers, Customized for Global Clients
Professional Technical&Sales Team | On-Time Delivery
12~40.5KV vacuum circuit breaker and switchgear
As a specialized vacuum circuit breaker and relative accessories manufacturer in China, we have profuse designs of ABB and Siemens with series VCB, our price is very competitive because we are a manufacturer, we are the source.
We have more than 20 years of experience in this industry, our VCB are widely export to Southeast Asia, Central Asia and South Amercia, Europe etc.
